Features Simulated sinewave inverter Wide input voltage range 12VDC available Overload and short circuit protection LCD display for comprehensive information
CAPACITY 1200VA/ 720W
INPUT
Voltage 230 VAC
Acceptable Voltage Range 90-280VAC
Frequency 50 Hz/60 Hz (Auto sensing)
OUTPUT AC Voltage Regulation (Batt. Mode) 10%
Efficiency (Peak) 82%
Transfer Time 20 ms typical
Waveform (Batt. Mode) Simulated sine wave
BATTERY & AC CHARGER Battery Voltage 12 VDC
Floating Charge Voltage 13.7 VDC 2%
Low Battery Alarm Voltage 10.2Vdc 2%
Shutdown Voltage 9.9Vdc 2%
Overcharge Protection 15.0Vdc 2%
PROTECTION
Full Protection Overload, short circuit and polarity reserve protection
PHYSICAL
Dimension, D X W X H (mm) 300 x 360 x 88
Net Weight (kgs) 4.6
OPERATING ENVIRONMENT
Humidity 0 to 90% Relative Humidity (Non-condensing)
